Velopedia Bicycle Archive
2003 Quintana Roo Ti-phoon Ultegra
Road race & triathlon bicycle from the Velopedia specification archive.
- Original MSRP
- $3,695.00
- Sizes
- 49cm, 51cm, 53cm, 55cm, 57cm, 59cm, 61cm
- Archive ID
- 39228
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 3Al/2.5V titanium |
| Fork | QR Carbon |
| Fork Material | Carbon fiber composite w/carbon fiber steerer, aero crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Shimano Ultegra |
|---|---|
| Shifters | Shimano Dura-Ace bar-end |
| Front Derailleur | Shimano Ultegra, bottom-pull/braze-on |
| Rear Derailleur | Shimano Ultegra SS |
| Crankset | Shimano Ultegra, 39/53 teeth |
| Bottom Bracket | Shimano BB-6500, 109.5mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, Buyer's choice of gearing |
| Chain | Shimano CN-HG93, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Shimano Ultegra Dual Pivot brakes, Dia-Compe 188 TRI levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated Cane Creek IS-5 Integrated |
|---|---|
| Handlebar | Profile Airwing |
| Handlebar Extensions | Profile Aerolite |
| Stem | 3T Forgie |
| Saddle | Selle San Marco ODS |
| Seatpost | Aluminum micro-adjust |
Wheels & Tires
| Hubs | Shimano Ultegra |
|---|---|
| Rims | Velocity Deep-V, 28-hole |
| Spokes | Stainless steel, 14/15ga. (2.0/1.8mm) double-butted |
| Spoke Nipples | Aluminum nipples |
| Front Tire | 650 x 23c Michelin Axial Pro Race |
| Wheel Size | 650c wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
