2018 Cannondale Fat CAAD 1

Archived: 2018 Cannondale Fat CAAD 1 · Mountain · Published sizes: XS, S, M, L, XL

• Confirm the frame markings and seller description match this archived model. Note every component that differs from the published build.
• Record the frame serial number. It should be legible, unaltered and consistent with the seller’s ownership history.
• Find the size marking on the bicycle and confirm the fit before judging the condition or price.

Archived: Frame: Fat CAAD, SmartForm C1 Alloy, BB30XL, SAVE, 1.5 Si head tube · Fork: Lefty Olaf, 2Spring, 100mm, PBR Isolated Damper Technology with Fat tune, 60mm offset

• Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.
• Stand behind and in front of the bicycle to look for obvious frame, fork or wheel misalignment. Ask directly about crashes, transport damage and repairs.

Archived: Fork: Lefty Olaf, 2Spring, 100mm, PBR Isolated Damper Technology with Fat tune, 60mm offset

• Inspect the fork stanchions for scratches or coating wear, look for oil or dirt rings at the seals, and cycle the fork through its travel while checking for binding or bushing play.
• Ask for dated fork-service records. A clean exterior does not establish the condition of internal seals, oil or bushings.

Archived: Shifters: Shimano SLX, 11-speed · Rear derailleur: Shimano XT, 11-speed · Crankset: Cannondale Si, BB30, Fat Offset SpideRing, X-Sync®, 30t · Bottom bracket: Cannondale BB30XL, 166mm spindle / 120mm shell · Rear cogs: Shimano SLX, 11-46, 11-speed · Chain: Shimano HG601, 11-speed

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: SRAM Guide R, Centerline Rotors 180/160mm

• Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.
• Before riding, test every installed brake separately at walking speed. Each should stop firmly and release cleanly without its control reaching the end of its usable travel.

Archived: Wheel size: 26" · Rims: Sun Ringle Mulefü​t 80 SL, 26”, Tubeless Ready · Hubs: Lefty 73 (front), Sun Ringle SRC, 197x12 thru (rear), 32 hole · Front tire: Schwalbe Jumbo Jim 26x4.8”, Snakeskin, tubeless-ready · Rear tire: Schwalbe Jumbo Jim 26x4.8”, Snakeskin, tubeless-ready

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.
• Remove and reinstall or closely inspect both wheel-retention systems. Axles or quick releases should tighten correctly with undamaged threads, hardware and dropouts.
• Confirm whether the bike is actually set up tubeless, whether both tires hold pressure, and when sealant and rim tape were last serviced.

Archived: Headset: Cannondale HeadShok Si · Handlebar: Cannondale C3 riser, Alloy, 4° upsweep, 9° backsweep, 760x15mm · Stem: Cannondale C3, 3D-forged 6061 Alloy, 1.5”, 31.8, 6°, 60mm · Seatpost: TransX Dropper Post, 31.6, 120mm drop, internal routing · Saddle: Fabric Scoop Shallow Elite

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Cycle the dropper post repeatedly. It should reach full travel, remain extended under load and have no unusual oil, excessive rotational play or damaged remote, cable, hose or battery.

• Before riding, confirm both wheels are secure, tires are safe, both brakes function, and the headset, handlebar, stem, cranks and pedals have no looseness.
• Begin at low speed. Test steering, braking and shifting progressively, then load the drivetrain and suspension only after the basic safety checks pass.
• Listen and feel for repeated knocks, grinding, skipping, brake pulsation or movement at joints. Stop the test if the bicycle cannot be controlled safely.
